1. Why Fender Size Matters

Selecting the correct fender size ensures full hull protection during docking, rafting, or mooring. Effective sizing accounts for your yacht’s length, displacement, and mooring context—especially in high-traffic marinas or challenging conditions.

Sizing Rule of Thumb:

  • Cylindrical fenders: ≈ 1 inch (25 mm) of diameter per 4–5 feet (1.2–1.5 m) of vessel length.

  • Spherical fenders: ≈ 2 inches (50 mm) diameter per 4–5 feet—useful for bow corners or beam ends.

This guideline may need adjustments for heavier yachts or more extreme mooring scenarios.

2. Fendertex Fender Size Guide & Specifications

Here’s a consolidated table—with accurate dimensions, weights, and recommended counts—for each Fendertex fender type by vessel length:

Vessel Length Model Type (HxØ or D×Hx×W) cm Weight Qty (per side)
4.5–9 m C62 Cylindrical 59.8 × 21.6 0.7 kg 3
9–13 m C73 Cylindrical 69.9 × 25.4 0.9 kg 4
13–15.8 m C84 Cylindrical 80.0 × 30.5 1.2 kg 4
15.8–18.9 m C104 Cylindrical 100.3 × 34.3 1.4 kg 5
18.9–29.9 m C124 Cylindrical 119.4 × 35.6 1.9 kg 6
29.9–40 m C145 Cylindrical 139.7 × 48.3 2.3 kg 7
40–54.9 m C175 Cylindrical 170.2 × 55.9 2.8 kg 8
54.9–70 m C207 Cylindrical 200.7 × 69.9 4.3 kg 9
70–100 m C248 Cylindrical 241.3 × 95.3 5.0 kg 10
— S60 Spherical 38.1 × 53.3 × 53.3 1.1 kg —
— S70 Spherical 45.7 × 61.0 × 61.0 1.4 kg —
— S80 Spherical 53.3 × 66.0 × 66.0 1.8 kg —
— S100 Spherical 66.0 × 86.4 × 86.4 2.4 kg —
— S120 Spherical 81.3 × 106.7 × 106.7 3.4 kg —

3. Placement & Quantity Recommendations

  • Use at least one fender per 10 ft (3 m) of waterline, with a minimum of three on smaller yachts for secure coverage.

  • Mount fenders so their middle just reaches the waterline. Too low—risk of marine growth; too high—risk riding up and impact loss.

  • For horizontal deployment on larger cylindrical models (C84+), be sure to use a Long Side Cover to protect the valve and maintain form.

4. Why Fendertex Outperforms Traditional Fenders

  • Superior strength-to-weight ratio: Light enough for effortless handling but engineered for high-impact protection.

  • Compact storage: Collapses to just 5–10% of inflated volume—critical space-saving advantage onboard.

  • Enhanced fit: Multiple shapes (cylindrical, spherical, tandem) and sizes meet diverse vessel configurations and docking scenarios.

  • Customization: Logo, color, and cover options align with yacht branding.
